These
units save time, labor and money in applications
where mixing is performed by rolling the container.
Fully adjustable to roll any round container from
a 20 litres to a 150 litres drum.
Features
Heavy-duty 6" diameter
Neoprene wheels, eight under each drum, can
be moved to clear hoops and bungs permitting
unlimited latitude in type of container rolled.
Neoprene wheels bleed the static
electricity generated by drum rotation.
Smooth running ball bearing
pillow blocks and solid welded steel base for
heavy-duty service.
Constant speed drive: 144RPM
which rotates 55-gallon drum at 37RPM. Note:
To compute revolving speed of other containers,
multiply diameter of wheels by RPM of wheels
and divide by diameter of container.
V-belt and expandable pulley-type
variable speed drive allows speeds from 76 to
190 RPM. Speeds can be changed when unit is
operating.
©
